Linux Bridge Networking with Network Namespaces and veth: Build a Virtual Layer 2 Network

Linux can act as much more than an endpoint on a network. With Linux bridges, network namespaces, and veth pairs, a single Linux host can become a complete virtual networking laboratory containing isolated hosts, virtual Ethernet links, switches, routing boundaries, and packet-capture points.

In the previous CorgiNetwork guide on Linux Network Namespaces, we created isolated networking environments and connected them with veth pairs.

That works extremely well when only two endpoints need a direct connection.

But what happens when three, five, or twenty virtual hosts need to share the same Layer 2 network?

This is where the Linux bridge becomes important.

According to the official Linux kernel Ethernet Bridge documentation, an Ethernet bridge operates at Layer 2 and forwards frames between network segments based on destination MAC addresses.

In practical terms, we can use a Linux bridge much like a virtual Ethernet switch.

This guide builds an end-to-end lab containing three network namespaces connected through a Linux bridge, then examines MAC learning, the forwarding database, ARP, packet capture, routing, Internet access, STP, VLAN filtering, and common bridge failures.

What Is a Linux Bridge?

A Linux bridge is a software implementation of Ethernet bridging inside the Linux networking stack.

Conceptually:

           Linux Bridge
          /      |      \
       port1   port2   port3
         |       |       |
       Host A  Host B  Host C

Unlike a traditional IP router, which primarily makes forwarding decisions using destination IP addresses and routing tables, an Ethernet bridge operates at Layer 2.

The official Linux Ethernet Bridging documentation describes a bridge as connecting network segments and filtering or forwarding frames based on destination MAC addresses.

Therefore, a useful simplified model is:

Router
   ↓
Destination IP
   ↓
Routing Table

versus:

Bridge
   ↓
Destination MAC
   ↓
Forwarding Database

This distinction is essential when troubleshooting Linux virtual networking.

Linux Bridge vs Physical Ethernet Switch

A Linux bridge behaves in many ways like a software Ethernet switch.

A physical switch might connect:

PC1 ───┐
PC2 ───┼── Ethernet Switch
PC3 ───┘

A Linux bridge can connect:

Namespace 1 ───┐
Namespace 2 ───┼── Linux Bridge
Namespace 3 ───┘

The major difference is that the switch exists inside the Linux kernel rather than as a separate hardware device.

This makes bridges extremely useful for:

  • virtual machines;
  • containers;
  • network namespaces;
  • virtualization hosts;
  • network laboratories;
  • VLAN-aware virtual networks;
  • virtual routers;
  • development environments.

Linux Bridge vs Network Namespace

These technologies solve different problems.

A network namespace provides network-stack isolation.

As explained in CorgiNetwork’s Linux Network Namespaces guide, a namespace can have its own interfaces, routing tables, sockets, firewall context, and networking configuration.

A bridge provides Layer 2 connectivity.

Therefore:

Network Namespace
       ↓
Creates isolated endpoint

while:

Linux Bridge
       ↓
Connects Ethernet endpoints

Combining them gives us:

Namespace A
     |
    veth
     |
     +---------+
               |
          Linux Bridge
               |
     +---------+
     |
    veth
     |
Namespace B

This is the foundation of our lab.

Linux Bridge vs veth

A veth pair behaves like a virtual Ethernet cable.

The Linux veth(4) documentation describes veth devices as interconnected pairs: packets transmitted on one endpoint are immediately received by the other.

Conceptually:

veth-a <================> veth-b

A bridge is different.

It can connect many Ethernet interfaces:

           br0
        /   |   \
      v1    v2   v3

Therefore:

veth = virtual cable

bridge = virtual switch

This mental model makes Linux virtual networking much easier to understand.

The Lab Architecture

We will build three isolated Linux network environments:

        ns-red
      10.10.10.11
           |
        veth-r
           |
        veth-r-br
           |
           |
     +-------------+
     |             |
     |     br0     |
     |             |
     +-------------+
       /           \
veth-b-br         veth-g-br
    |                 |
 veth-b             veth-g
    |                 |
 ns-blue           ns-green
10.10.10.12       10.10.10.13

All three namespaces will belong to:

10.10.10.0/24

Our Linux host will act as the virtual switch.

Step 1: Check Existing Network Configuration

Before creating anything, inspect the host:

ip -br link

Then:

ip -br addr

Check existing bridges:

ip link show type bridge

The ip-link(8) documentation supports bridge as a Linux link type and provides the interface used to create and configure bridge devices.

Never assume that br0 is unused on a production machine.

Virtualization software such as KVM, libvirt, Docker, LXD, or other platforms may already have created bridges.

Step 2: Create Three Network Namespaces

Create RED:

sudo ip netns add ns-red

Create BLUE:

sudo ip netns add ns-blue

Create GREEN:

sudo ip netns add ns-green

Verify:

ip netns list

You should see:

ns-red
ns-blue
ns-green

Bring loopback up inside each namespace:

sudo ip netns exec ns-red ip link set lo up
sudo ip netns exec ns-blue ip link set lo up
sudo ip netns exec ns-green ip link set lo up

We now have three isolated network stacks.

Step 3: Create the Linux Bridge

Create:

sudo ip link add br0 type bridge

Bring it up:

sudo ip link set br0 up

Verify:

ip link show br0

You can also list all bridge devices:

ip link show type bridge

At this stage:

Linux Host
    |
   br0

exists, but no ports are connected to it.

Step 4: Create the RED veth Pair

Create:

sudo ip link add veth-r-br type veth peer name veth-r

Conceptually:

veth-r-br <============> veth-r

Move the namespace-facing endpoint:

sudo ip link set veth-r netns ns-red

The topology becomes:

Host                         ns-red

veth-r-br <=============> veth-r

Now attach the host endpoint to the bridge:

sudo ip link set veth-r-br master br0

Bring it up:

sudo ip link set veth-r-br up

Inside RED:

sudo ip netns exec ns-red ip link set veth-r up

Step 5: Create the BLUE veth Pair

Create:

sudo ip link add veth-b-br type veth peer name veth-b

Move:

sudo ip link set veth-b netns ns-blue

Attach:

sudo ip link set veth-b-br master br0

Bring up the host side:

sudo ip link set veth-b-br up

Then:

sudo ip netns exec ns-blue ip link set veth-b up

Step 6: Create the GREEN veth Pair

Create:

sudo ip link add veth-g-br type veth peer name veth-g

Move:

sudo ip link set veth-g netns ns-green

Attach:

sudo ip link set veth-g-br master br0

Bring it up:

sudo ip link set veth-g-br up

Then:

sudo ip netns exec ns-green ip link set veth-g up

Now we have:

                    br0
               /     |      \
              /      |       \
       veth-r-br  veth-b-br  veth-g-br
           |          |          |
        veth-r      veth-b     veth-g
           |          |          |
        ns-red     ns-blue    ns-green

The bridge ports can be inspected with the bridge utility documented in the official bridge(8) manual.

Run:

bridge link show

You can also use:

ip link show master br0

to show interfaces attached to br0.

Step 7: Configure Namespace IP Addresses

RED:

sudo ip netns exec ns-red \
ip addr add 10.10.10.11/24 dev veth-r

BLUE:

sudo ip netns exec ns-blue \
ip addr add 10.10.10.12/24 dev veth-b

GREEN:

sudo ip netns exec ns-green \
ip addr add 10.10.10.13/24 dev veth-g

Verify:

sudo ip netns exec ns-red ip -br addr
sudo ip netns exec ns-blue ip -br addr
sudo ip netns exec ns-green ip -br addr

Our virtual LAN is now:

                 br0
                  |
       10.10.10.0/24 LAN
        /         |        \
       /          |         \
10.10.10.11  10.10.10.12  10.10.10.13
   RED          BLUE          GREEN

Notice that we have not assigned an IP address to br0.

That is intentional.

A Linux bridge does not require an IP address merely to forward Ethernet frames.

Step 8: Test RED to BLUE

From RED:

sudo ip netns exec ns-red \
ping 10.10.10.12

The packet path is approximately:

ns-red
   ↓
veth-r
   ↓
veth-r-br
   ↓
br0
   ↓
veth-b-br
   ↓
veth-b
   ↓
ns-blue

Test GREEN:

sudo ip netns exec ns-red \
ping 10.10.10.13

Then BLUE to GREEN:

sudo ip netns exec ns-blue \
ping 10.10.10.13

If all three work, the bridge is successfully switching Ethernet frames between the namespaces.

Understanding MAC Address Learning

Ethernet bridges need to know where destination MAC addresses are located.

Suppose RED sends traffic toward BLUE.

Initially, the bridge sees a frame arriving from:

RED MAC

on:

veth-r-br

The bridge can learn:

RED MAC → veth-r-br

When BLUE responds:

BLUE MAC → veth-b-br

The bridge gradually builds a forwarding database.

Conceptually:

MAC Address          Bridge Port

RED-MAC      →       veth-r-br
BLUE-MAC     →       veth-b-br
GREEN-MAC    →       veth-g-br

This is one of the most important concepts in Ethernet switching.

Inspect the Linux Bridge FDB

Linux exposes the forwarding database through the bridge command.

Run:

bridge fdb show br br0

The official bridge(8) documentation provides commands for inspecting and manipulating bridge forwarding database entries, VLAN information, multicast databases, and bridge ports.

Generate traffic between all namespaces and inspect the FDB again:

bridge fdb show br br0

You should see dynamic MAC entries associated with bridge ports.

This gives you direct evidence of what the bridge has learned.

FDB vs ARP Table

Do not confuse:

Bridge FDB

with:

ARP / neighbor table

They solve different problems.

The bridge FDB maps:

MAC address
      ↓
bridge port

The ARP/neighbor table maps:

IP address
      ↓
MAC address

For example:

ARP

10.10.10.12
      ↓
AA:BB:CC:DD:EE:FF

while:

FDB

AA:BB:CC:DD:EE:FF
      ↓
veth-b-br

Together:

IP
 ↓
MAC
 ↓
Bridge Port

This distinction becomes extremely valuable during troubleshooting.

Inspect ARP Inside the Namespaces

From RED:

sudo ip netns exec ns-red ip neigh

After pinging BLUE you might see an entry representing:

10.10.10.12 → BLUE MAC

Compare with:

bridge fdb show br br0

You now have two perspectives:

Namespace:
IP → MAC

Bridge:
MAC → Port

If you’re troubleshooting unusual neighbor behavior on a multi-NIC host, CorgiNetwork’s Linux ARP Flux and Multiple NICs on the Same Subnet explores the ARP side in greater depth.

Packet Capture: Watch ARP Through the Bridge

Run:

sudo tcpdump -eni veth-r-br arp

Then clear RED’s neighbor cache:

sudo ip netns exec ns-red ip neigh flush all

Generate:

sudo ip netns exec ns-red \
ping -c 1 10.10.10.12

You should see ARP traffic before normal IP communication.

Conceptually:

RED:

Who has 10.10.10.12?
        ↓
Broadcast Ethernet Frame
        ↓
       br0
     ↙     ↘
 BLUE     GREEN

BLUE responds with its MAC address.

The bridge then gains additional information about the participating endpoints.

Capture Traffic on the Bridge

Try:

sudo tcpdump -eni br0

Then generate:

sudo ip netns exec ns-red ping 10.10.10.12

Packet capture helps answer questions such as:

  • Did the ARP request leave RED?
  • Did the bridge receive it?
  • Did BLUE respond?
  • Did ICMP reach the destination?
  • Did the reply return?

For deeper packet analysis, continue with CorgiNetwork’s Wireshark Explained guide.

Give the Linux Bridge an IP Address

Our bridge currently acts only as a Layer 2 switch.

We can make the Linux host itself participate in the virtual LAN.

Assign:

sudo ip addr add 10.10.10.1/24 dev br0

Verify:

ip -br addr show br0

Now:

                 Linux Host
                 10.10.10.1
                      |
                     br0
                /     |      \
               /      |       \
            RED      BLUE     GREEN
             .11      .12      .13

Test from RED:

sudo ip netns exec ns-red \
ping 10.10.10.1

The host is now another Layer 3 participant on the bridged network.

Important: Put the IP on the Bridge

Suppose a physical interface becomes a bridge port.

A common Linux bridge architecture is:

Physical NIC
     ↓
    br0

Once the interface participates as a bridge port, Layer 3 configuration is generally placed on the bridge interface rather than treated as ordinary independent Layer 3 configuration on the enslaved port.

Conceptually:

Wrong mental model:

eth0 → IP
 |
br0


Better model:

eth0
 |
br0 → IP

This distinction prevents many bridge configuration problems.

Give the Namespaces a Default Gateway

Because:

br0 = 10.10.10.1

we can configure it as the gateway.

RED:

sudo ip netns exec ns-red \
ip route add default via 10.10.10.1

BLUE:

sudo ip netns exec ns-blue \
ip route add default via 10.10.10.1

GREEN:

sudo ip netns exec ns-green \
ip route add default via 10.10.10.1

Inspect:

sudo ip netns exec ns-red ip route

Expected conceptually:

10.10.10.0/24 dev veth-r
default via 10.10.10.1

Now the Linux host can become the Layer 3 gateway for destinations outside the virtual LAN.

Enable Host Routing

Check:

sysctl net.ipv4.ip_forward

For a lab where the host intentionally operates as a router:

sudo sysctl -w net.ipv4.ip_forward=1

The architecture becomes:

Namespaces
    ↓
   br0
    ↓
Linux Host Routing
    ↓
Physical Interface
    ↓
Upstream Router

At this point we have combined:

Layer 2 bridging
+
Layer 3 routing

inside one Linux machine.

Internet Access from the Namespaces

Assume the Linux host has an Internet-facing interface such as:

eth0

and the upstream router has no route for:

10.10.10.0/24

The host may need source NAT.

The conceptual packet path becomes:

ns-red
10.10.10.11
     ↓
    br0
     ↓
Linux Routing
     ↓
Firewall/NAT
     ↓
eth0
     ↓
Internet

Before changing firewall configuration, inspect the current nftables rules:

sudo nft list ruleset

Do not flush an existing production firewall merely to provide namespace connectivity.

If the upstream router already knows:

10.10.10.0/24 via LINUX_HOST

NAT may not be necessary.

Always distinguish routing from NAT.

Bridge Traffic vs Routed Traffic

This is a critical troubleshooting concept.

Traffic from:

RED → BLUE

on the same subnet is bridged:

RED
 ↓
br0
 ↓
BLUE

Traffic from:

RED → Internet

uses:

RED
 ↓
br0
 ↓
Linux IP routing
 ↓
uplink

Therefore:

Same Layer 2 network
        ↓
Bridge forwarding

while:

Different IP network
        ↓
Routing

Do not troubleshoot both paths as though they were identical.

Linux Bridge and STP

Ethernet loops can be dangerous.

Consider:

       +------ Switch A ------+
       |                      |
       |                      |
       +------ Switch B ------+

Layer 2 loops can create repeated frame forwarding and broadcast storms.

Linux bridges support Spanning Tree Protocol configuration.

The official ip-link(8) bridge documentation exposes stp_state as a bridge option.

Inspect detailed bridge information:

ip -d link show br0

A bridge can be created with STP enabled, for example:

sudo ip link add br1 type bridge stp_state 1

Whether STP should be enabled depends on topology.

For a simple isolated lab with no Layer 2 loops, it may not be necessary.

For networks connected to external switching infrastructure, loop prevention must be designed deliberately.

Linux Bridge VLAN Filtering

Linux bridges can also be VLAN-aware.

The ip-link bridge configuration includes:

vlan_filtering

and the bridge(8) utility provides VLAN management commands.

Conceptually:

                 br0
            VLAN-aware bridge
             /            \
         Port A           Port B
         VLAN 10          VLAN 20

Inspect:

bridge vlan show

A bridge with VLAN filtering can provide virtual switching architectures that would otherwise require several separate bridges.

This is important for:

  • virtualization hosts;
  • trunk ports;
  • container networks;
  • multi-tenant labs;
  • virtual routers;
  • VLAN-aware KVM networking.

A dedicated CorgiNetwork article should cover this separately because bridge VLAN filtering deserves a complete end-to-end lab.

Bridge Port State

Inspect:

bridge link show

The official bridge(8) manual exposes bridge-port configuration including state, learning, flooding, STP-related parameters, hairpin behavior, multicast handling, isolation, and other attributes.

This makes bridge link one of the most important diagnostic commands when a port appears connected but frames do not behave as expected.

MAC Learning

Linux bridge ports normally participate in MAC learning.

Conceptually:

Frame enters port 1

Source MAC = AA:AA:AA:AA:AA:AA

Bridge learns:

AA:AA:AA:AA:AA:AA → port 1

Later, a frame destined for that MAC can be sent specifically toward port 1 rather than being flooded unnecessarily.

Inspect:

bridge fdb show

Generate traffic:

sudo ip netns exec ns-red ping 10.10.10.12

Then inspect again:

bridge fdb show br br0

This is a practical way to watch the virtual switch learn.

Unknown Unicast and Flooding

Suppose the bridge receives a frame for a destination MAC it has not learned.

Conceptually:

Unknown destination MAC
          ↓
         br0
      ↙    ↓    ↘
   port1 port2 port3

The bridge may flood the frame to eligible ports.

Once the destination responds and its location is learned:

Destination MAC
      ↓
Known bridge port

future traffic can be forwarded more selectively.

Understanding this explains why packet captures sometimes show traffic on several bridge ports during initial communication.

Broadcast Traffic

ARP requests use Ethernet broadcast.

Therefore:

RED
 ↓
ARP request
 ↓
br0
 ↙       ↘
BLUE    GREEN

This is normal.

If broadcast traffic fails to reach another namespace, inspect:

bridge link show

and:

tcpdump

before modifying IP routes.

The problem may be Layer 2, not Layer 3.

Troubleshooting: Namespace Cannot Reach Another Namespace

Start with the endpoint.

Check RED:

sudo ip netns exec ns-red ip -br link

Then:

sudo ip netns exec ns-red ip -br addr

Check its route:

sudo ip netns exec ns-red ip route

Then inspect the host-side port:

ip link show veth-r-br

Check bridge membership:

ip link show master br0

Then:

bridge link show

Finally:

bridge fdb show br br0

This progresses logically from:

Endpoint
 ↓
veth
 ↓
bridge port
 ↓
bridge
 ↓
destination

Troubleshooting: veth Is Not Attached to the Bridge

A common mistake is creating:

veth-r-br

but forgetting:

sudo ip link set veth-r-br master br0

Check:

ip link show master br0

If the interface is missing, the bridge cannot forward traffic through it.

Troubleshooting: Interface Is Down

Check:

ip -br link

and inside the namespace:

sudo ip netns exec ns-red ip -br link

Remember that both ends matter:

veth-r
   ↕
veth-r-br

Do not assume that creating a veth pair automatically completes the network configuration.

Troubleshooting: ARP Fails

From RED:

sudo ip netns exec ns-red ip neigh

Capture:

sudo tcpdump -eni veth-r-br arp

Then:

sudo tcpdump -eni veth-b-br arp

Generate:

sudo ip netns exec ns-red ping 10.10.10.12

Ask:

Does ARP leave RED?

Does it reach br0?

Does it reach BLUE?

Does BLUE respond?

Does the response return?

This immediately narrows the problem.

Troubleshooting: MAC Is Learned on the Wrong Port

Inspect:

bridge fdb show br br0

Identify the destination MAC:

sudo ip netns exec ns-red ip neigh

Then correlate:

IP
 ↓
MAC
 ↓
FDB
 ↓
Bridge Port

This technique is much more powerful than repeatedly running ping.

Troubleshooting: Same Subnet Works but Internet Does Not

If:

RED → BLUE

works but:

RED → Internet

does not, the bridge is probably functioning.

Move the investigation to Layer 3:

sudo ip netns exec ns-red ip route

Then:

sudo ip netns exec ns-red \
ip route get 8.8.8.8

Check the gateway:

sudo ip netns exec ns-red ping 10.10.10.1

Then host forwarding:

sysctl net.ipv4.ip_forward

Then:

ip route

and:

sudo nft list ruleset

This prevents wasting time troubleshooting a working bridge.

Troubleshooting Multi-Homed Hosts

Suppose your Linux host has:

eth0 → ISP A

eth1 → ISP B

The namespace may correctly reach:

br0

while the host sends traffic through the wrong external interface.

Check:

ip route get 8.8.8.8

Then:

ip rule

and:

ip route show table all

If the wrong NIC is selected, use CorgiNetwork’s Linux Traffic Uses the Wrong Interface guide.

For deliberate multi-table routing, continue with Linux Policy Routing with ip rule and Multiple Routing Tables.

Linux Bridge and rp_filter

Bridging itself is Layer 2, but once the host begins routing between the bridge and other networks, reverse-path filtering can become relevant.

For complex multi-homed or asymmetric environments, inspect:

sysctl -a 2>/dev/null | grep '\.rp_filter'

Do not disable it blindly.

If asymmetric return paths are involved, use CorgiNetwork’s Linux rp_filter and Asymmetric Routing to understand how strict and loose reverse-path validation affect traffic.

Linux Bridge with Policy Routing

A particularly powerful design is:

Namespace
    ↓
   veth
    ↓
Linux Bridge
    ↓
Host Layer 3
    ↓
ip rule
    ↓
Custom Routing Table
    ↓
Selected Gateway

For example:

ns-red
   ↓
ISP A

ns-blue
   ↓
ISP B

Policy routing can select the correct uplink based on source address, firewall mark, or other supported policy criteria.

CorgiNetwork’s Linux Policy Routing guide provides the routing-table layer required for this architecture.

Linux Bridge with Netplan

On Ubuntu servers, persistent bridge configuration may be managed using Netplan rather than manually running ip commands after every boot.

This becomes especially relevant when combining:

Bridge
+
Multiple physical NICs
+
Multiple gateways
+
Policy routing

For the gateway side of that architecture, see CorgiNetwork’s Netplan Multiple Default Routes and Policy Routing.

A future dedicated guide can cover persistent Netplan bridge configuration separately.

Complete Diagnostic Workflow

When Linux bridge networking fails, use this order.

1. Check namespaces

ip netns list

2. Check namespace interfaces

sudo ip netns exec NAME ip -br link

3. Check addresses

sudo ip netns exec NAME ip -br addr

4. Check host veth interfaces

ip -br link

5. Check bridge existence

ip link show type bridge

6. Check bridge ports

ip link show master br0

7. Check detailed port state

bridge link show

8. Check FDB

bridge fdb show br br0

9. Check neighbor table

sudo ip netns exec NAME ip neigh

10. Capture ARP

sudo tcpdump -eni PORT arp

11. Capture ICMP

sudo tcpdump -eni PORT icmp

12. Check namespace routes

sudo ip netns exec NAME ip route

13. Check host routing

ip route

14. Check policy routing

ip rule
ip route show table all

15. Check firewall

sudo nft list ruleset

This follows the packet from source to destination instead of guessing.

Bridge Troubleshooting Map

Namespace A cannot reach Namespace B
                |
                v
         Interface UP?
          /          \
        NO           YES
        |             |
     Bring UP         v
                Correct IP?
                 /       \
               NO        YES
               |          |
            Fix IP        v
                     veth peer UP?
                      /       \
                    NO        YES
                    |          |
                 Bring UP      v
                         Attached to br0?
                           /        \
                         NO         YES
                         |           |
                      Attach        v
                             Bridge UP?
                              /      \
                            NO       YES
                            |         |
                         Bring UP     v
                               ARP crossing?
                                /       \
                              NO        YES
                              |          |
                         Debug L2       v
                                   FDB correct?
                                    /       \
                                  NO        YES
                                  |          |
                              Debug MAC     v
                                         Check
                                      destination

Cleanup the Lab

Remove the namespaces:

sudo ip netns del ns-red
sudo ip netns del ns-blue
sudo ip netns del ns-green

Delete the bridge:

sudo ip link del br0

Because the veth namespace endpoints are associated with the namespaces, namespace deletion also cleans up the relevant virtual Ethernet pairs.

Verify:

ip netns list

Then:

ip link show type bridge

Frequently Asked Questions

What is a Linux bridge?

A Linux bridge is a software Ethernet bridge implemented in the Linux networking stack. It connects Ethernet interfaces and forwards frames primarily according to MAC-address information.

Is a Linux bridge the same as a router?

No.

A bridge primarily operates at Layer 2 using Ethernet/MAC information.

A router operates at Layer 3 using IP routing decisions.

A Linux host can perform both functions simultaneously.

Is a Linux bridge the same as a network namespace?

No.

A namespace creates an isolated networking environment.

A bridge connects Layer 2 endpoints.

They are commonly used together.

What is a veth pair?

A veth pair is a pair of interconnected virtual Ethernet interfaces.

One endpoint can be placed inside a namespace while the other is connected to a Linux bridge.

Does a Linux bridge need an IP address?

Not merely to switch Ethernet frames.

Assigning an IP address to the bridge allows the Linux host itself to participate at Layer 3 on that network.

How do I create a Linux bridge?

Use:

sudo ip link add br0 type bridge
sudo ip link set br0 up

How do I attach an interface to a bridge?

Use:

sudo ip link set INTERFACE master br0

How do I list bridge ports?

Use:

bridge link show

or:

ip link show master br0

How do I view learned MAC addresses?

Use:

bridge fdb show br br0

What is the Linux bridge FDB?

The Forwarding Database associates learned MAC addresses with bridge ports so the bridge can make Layer 2 forwarding decisions.

Can a Linux bridge support VLANs?

Yes.

Linux bridges support VLAN-aware configurations, including VLAN filtering and per-port VLAN configuration.

Does Linux bridge support STP?

Yes.

Linux bridge configuration supports Spanning Tree Protocol settings.

Can network namespaces connected to a bridge access the Internet?

Yes.

Typically the Linux host must provide appropriate Layer 3 routing, firewall forwarding, and either an upstream route or NAT depending on the network architecture.

Conclusion

Linux bridges, network namespaces, and veth pairs form one of the most useful combinations in advanced Linux networking.

A network namespace gives us:

Isolated network stack

A veth pair gives us:

Virtual Ethernet cable

A Linux bridge gives us:

Virtual Ethernet switch

Together:

                 Linux Host

                    br0
             /       |       \
            /        |        \
         veth      veth      veth
           |         |         |
       Namespace  Namespace  Namespace
          RED       BLUE      GREEN

The official Linux kernel Ethernet Bridge documentation provides the underlying Layer 2 bridge model, while ip-link(8) documents creation and configuration of bridge interfaces and the bridge(8) utility exposes bridge ports, FDB entries, VLAN configuration, multicast information, and other bridge state.

The most important commands from this lab are:

ip link add br0 type bridge
ip link set br0 up

ip link add veth-host type veth peer name veth-ns
ip link set veth-ns netns NAME
ip link set veth-host master br0

bridge link show
bridge fdb show br br0
bridge vlan show

But troubleshooting should always follow the packet.

If traffic never crosses the veth pair, investigate the endpoint.

If ARP reaches the bridge but not another port, investigate Layer 2 bridge state.

If namespace-to-namespace communication works but Internet access fails, investigate routing, forwarding, firewall rules, NAT, and the upstream return path.

For namespace fundamentals, use CorgiNetwork’s Linux Network Namespaces guide.

For multi-homed routing problems, use Linux Traffic Uses the Wrong Interface.

For multiple routing tables, continue with Linux Policy Routing with ip rule and Multiple Routing Tables.

For reverse-path problems, see Linux rp_filter and Asymmetric Routing.

For unusual ARP behavior, see Linux ARP Flux and Multiple NICs on the Same Subnet.

And for persistent Ubuntu multi-gateway configurations, use Netplan Multiple Default Routes and Policy Routing.

This extends the CorgiNetwork advanced networking cluster:

Linux Routing Problems
        ↓
Multiple Default Routes
        ↓
ARP Flux
        ↓
rp_filter / Asymmetric Routing
        ↓
Policy Routing
        ↓
VRF
        ↓
Network Namespaces
        ↓
veth
        ↓
Linux Bridge
        ↓
Bridge FDB / MAC Learning
        ↓
VLAN-Aware Linux Bridge

The next logical article is Linux Bridge VLAN Filtering Explained: Build a VLAN-Aware Virtual Switch with Network Namespaces, where we can build VLAN 10 and VLAN 20 on a single Linux bridge, configure access and trunk ports, inspect bridge vlan show, and troubleshoot inter-VLAN isolation.

Leave a Reply

Your email address will not be published. Required fields are marked *
